  • RL28 Specifications

    Replacement Stickers for sides of an RL28.

    These stickers are no longer available but you can make your own or have them made at a computer cut sign outlet.
    Right Click here and select "Save Target As.." to save a high resolution image of the sticker on your PC.

    Technical Details

    Length Overall 8.54 metres 28 feet
    Length Water Line 7.2 metres 23 ft 9 in
    Beam 2.41 metres 8 ft 1 in
    Sail-away Weight
    (Including mast, boom, mainsail and one headsail
    excluding spinnaker gear, motor, fuel tanks, batteries, anchors, life jackets, fenders)
    1360 kg 3000 lb
    Ballast Ratio 40 % 40 %
    Minimum draft (keel up) 0.41 metres 1 ft 4 in
    Maximum draft (keel down) 1.45 metres 4 ft 9 in
    Water storage - galley 55 litres 12 gallons
    Water storage - shower/wash basin

    135 litres 30 gallons
    Mast (alloy) 8.23 metres 27 ft

    Sails

    Working Sail Area 23 sq metres 247 sq ft
    Main Sail 12.54 sq metres 135 sq ft
    Genoa (No 1) 10.22 sq metres 110 sq ft
    Genoa (No 2) 7.43 sq metres 80 sq ft
    Jib 6.04 sq metres 65 sq ft
    Spinnaker 25.08 sq metres 270 sq ft

    The RL 28 can have a recessed motor well to house an outboard or can be fitted with a small Volvo Sail-Drive diesel.
